Tempat asal: | Jiangsu, Cina |
Nama merek: | Eceng |
Sertifikasi: | CE ISO |
Nomor model: | Q20L-1 |
Kuantitas min Order: | 1 set |
---|---|
Harga: | $32,800.00/Sets 1-1 Sets |
Kemasan rincian: | paket sesuai dengan transportasi untuk 6000bph Mesin botol PET blow otomatis / blower preform |
Waktu pengiriman: | 45 hari |
Syarat-syarat pembayaran: | L/C, T/T, Western Union |
Menyediakan kemampuan: | 10 Set/Set per Bulan |
Plastic Processed: | PET | Bottle Volume(ml): | 2000 ml |
---|---|---|---|
Blow Moulding Type: | Stretch Blow Moulding | Voltage: | 380V/50HZ, 3phase 380V/220V/415V 50HZ |
Applicable Industries: | Food & Beverage Factory | Core Components: | Bearing, Motor, Pump, Gear, PLC, Pressure vessel |
After-sales Service Provided: | Engineers available to service machinery overseas, Free spare parts, Online support, Field installation, commissioning and training, Field maintenance and repair service, Video technical support | Production Capacity (BPH): | 400 BPH |
Cahaya Tinggi: | Mesin pembuat botol air 400bph,mesin blowing 400bph untuk botol pet,mesin blowing untuk botol pet 10l 20l |
Barang
|
|
Q20L-1
|
|
Spesifikasi jenis botol
|
Rongga
|
1
|
|
|
Keluaran teori
|
400bph
|
|
|
Volume maks
|
20L
|
|
|
Mulut botol diameter keseluruhan maksimum
|
150mm
|
|
|
Diameter botol terbesar
|
350mm
|
|
|
Tinggi maksimum botol
|
550mm
|
|
Spesifikasi daya
|
Kuantitas tabung cahaya
|
48pcs
|
|
|
|
1.5KW
|
|
|
Daya pemanas maksimum
|
72KW
|
|
|
Semua instalasi mesin listrik
|
75KW
|
|
|
Konsumsi aktual
|
52,5KW
|
|
|
Tekanan pekerjaan
|
7-9kg/cm2
|
|
|
Konsumsi gas bertekanan rendah
|
1600L/mnt
|
|
|
Tiup tekanan botol
|
25-35kg/cm2
|
|
|
Konsumsi gas bertekanan lebih tinggi
|
2000-3000Ltr/mnt
|
|
Spesifikasi tekanan udara
|
Tekanan pekerjaan
|
5-6 kg/cm2
|
|
|
Kisaran suhu
|
10 ℃
|
|
|
Konsumsi
|
12000kkal/jam
|
|
|
Aliran air beku
|
88L/mnt
|
|
Spesifikasi mesin
|
Ukuran mesin
|
5.2x2.0x2.0
|
|
|
Berat mesin
|
6ton
|
